Specifications: |
|
|
Input |
Impedance: 1 meg |
| EQ |
Bass: +/- 12 db @150 hz, Treble: +/- 12db @ 5K hz. |
|
Shape |
+ 5
db @ 3Khz, -5 db @ 1500 hz, + 5 db @ 100 hz. |
|
Notch Filter |
Feedback elimination range: 100 to 350 hz, attenuation -18 db. |
|
Output Impedance |
Balanced Line XLR out - 600 ohms, Unbalanced Line 1/4" out - 680
ohms |
|
Power Supply |
9
volt on board battery ( optional 9vdc 500 ma plug in 110 volt power
supply) |
|
Phantom power |
48
volt phantom power when available through XLR output from mixer or
amp |
| |
|
|
Dimensions |
Steel Enclosure: 5" x 7.5" x 2" |
|
Weight |
2.25
lbs |
| |
|
